SKU:
VER580G

VER580G – Glass Simple Verona Square Profile 180 Degree Glass to Glass Hinge, Factory Set 5 Degree Positive Close

Brand :

(No reviews yet) Write a Review
$80.10 - $94.14
Compare to:
V1E580, VEN580

Description

  • Compare to V1E580, VEN580
  • Self-centering glass to glass hinge
  • For 3/8” – 1/2” (12mm) tempered glass
  • 5 degree offsest
  • Solid brass



Other Details

  • Edge: Square profile



Technical Specifications



  • If using 2 hinges, maximum door weight is 110 lbs.
  • If using 3 hinges, maximum door weight is 140 lbs.
  • Maximum door width is 36” (864 mm).
  • DO NOT exceed the maximum door weight OR door width.
  • Only monolithic tempered glass may be used.
  • Avoid using power tools during hinge installation as these may damage the finish.





Product Details



The Verona series hinge offers appealing features. It is a solid brass glass to glass hinge, available in various popular finishes. This hinge comes pre-set at 85 degrees for more positive pressure against the jamb when closed. If desired, the pin can be rotated to the 90 degree setting for normal closure.



Cleaning Your Glass Simple Hardware



  • Dry hardware after use to minimize water spots and other discoloration.
  • Avoid harsh or abrasive cleaning agents, scrub brushes, etc. as these will damage the finish.
  • Use a mild mixture of gentle liquid soap and water and test on an inconspicuous part of the hardware first.
  • After washing, thoroughly rinse with clean warm water and buff dry.



Hinge Care



  • Glass Simple hinges arrive pre-greased for quiet operation.
  • In the event of a hinge squeaking, add a several drops of mult-purpose oil around the nylon washer.
  • If the hinge is taken apart, the interior components should be lubricated with a little bit of white lithium grease.
  • Avoid spray-on lubricants.
Compare to:
V1E580, VEN580
