PRO01 - Glass Simple Proxima Beveled Standard Duty Pivot Hinge

• Compare to PAT01, PPH01
• Standard duty beveled profile top or bottom mount pivot hinge
• Designed for 3/8" tempered or laminated tempered glass
• Top and bottom mount design allows more glass to remain visible
• Self-centering within 15 degrees of closing position
• Optional 5 degree pivot pin provides a firmer positive close against a jamb or seal, (PIVPIN38 sold separately)
• Maximum door capacity of 100 lbs. and 31" width when using two hinges
• Solid brass construction
• Designed for residential bath and commercial hotel applications
• Available in multiple finishes to coordinate with Glass Simple shower hardware

The 100 lb. maximum door weight, 31" maximum width, self-centering action, and solid brass construction are supported by the PAT01 specifications.

CLEANING YOUR GLASS SIMPLE HARDWARE

• Dry hardware after use to minimize water spots and other discoloration.
• Avoid harsh or abrasive cleaning agents, scrub brushes, etc. as these will damage the finish.
• Use a mild mixture of gentle liquid soap and water and test on an inconspicuous part of the hardware first.
• After washing, thoroughly rinse with clean warm water and buff dry.

CALIFORNIA PROPOSITION 65 WARNING

 WARNING: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
